Length(L) |
1.0" |
1.5" |
2.0" |
2.5" |
3.0" |
4.0" |
5.0" |
|
|
Head dia (D) |
Min |
5.60 |
7.00 |
7.50 |
7.50 |
8.20 |
8.20 |
8.20 |
|
Max |
6.00 |
7.40 |
7.90 |
7.90 |
8.60 |
8.60 |
8.60 |
|
|
Head Thickness(h) |
3.00 |
3.00 |
3.00 |
3.00 |
3.00 |
3.00 |
3.00 |
|
|
Shank dia (d) |
3.20 |
3.80 |
4.00 |
4.00 |
4.70 |
4.70 |
4.70 |
|
|
No.of Grooves |
8.00 |
8.00 |
8.00 |
8.00 |
8.00 |
8.00 |
8.00 |
|
All dimensions are in mm.
